Mainboard MSI MPG Z890 EDGE TI WIFI

📌 Cam Kết của KHO CÔNG NGHỆ ONLINE
✍️ Sản phẩm mới chính hãng 100%
✍️ Bảo hành 36 Tháng - Tại TTBH của Hãng hoặc Shop đều được ( qua serial trên sản phẩm)
✍️ Đổi trả 15 ngày đầu: Với các lỗi nhà sản xuất, hư hỏng trong quá trình vận chuyển, giao sai hoặc thiếu phụ kiện.
_________________________

Thông số kỹ thuật:

- Chipset: INTEL Z890

- CPU: LGA 1851, Supports Intel Core Ultra Processors (Series 2)

- Memory
  + 4 x DDR5 UDIMM, Max. 256GB
  + Memory Speed: 4800–6400 MT/s (JEDEC), Up to 9200+ MT/s (OC)
  + Max. OC:
 • 1DPC 1R: 9200+ MT/s
 • 1DPC 2R: 7200+ MT/s
 • 2DPC 1R: 6400+ MT/s
 • 2DPC 2R: 5600+ MT/s
  + Supports Intel POR Speed and JEDEC Speed
  + Supports Memory Overclocking and Intel XMP 3.0
  + Supports Dual-Controller Dual-Channel mode
  + Supports Non-ECC, Un-buffered memory
  + Supports CUDIMM

- Onboard Graphics
 + 1x HDMI (Supports HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz)
 + 2x Type-C DisplayPort
 + ThundeboltTM 4 ports, , supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K 120Hz / 8K 60Hz

- Slot
 + 2x PCI-E x16 slot
 + 1x PCI-E x1 slot
 + PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
 + PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset)
 + PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
• PCI_E1 support manual BIOS adjustment to X8+X8 / X8+X4+X4

- Audio
  + Realtek ALC1220P Codec
  + 7.1-Channel High Definition Audio
  + Supports S/PDIF output

- Storage
  + 5 × M.2 Slots
  + M.2_1: PCIe 5.0 x4 (CPU, 2280/2260)
  + M.2_2: PCIe 4.0 x4 (CPU, 2280/2260)
  + M.2_3: PCIe 4.0 x4 (Chipset, 2280/2260)
  + M.2_4: PCIe 4.0 x4 (Chipset, 22110/2280)
  + M.2_5: PCIe 4.0 x4 / SATA (Chipset, 22110/2280/2260)
  + 4 × SATA 6Gb/s

- RAID:
  + Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices / for M.2 NVMe storage devices

- Onboard Thunderbolt
  + Thunderbolt
  + 2 × Thunderbolt 4 (Rear)
  + Up to 40Gbps (Thunderbolt) / 20Gbps (USB4) / 10Gbps (USB 3.2)
  + 15W Power Delivery (5V/3A)
  + Daisy-chain: Up to 3 × Thunderbolt 4 or 5 × Thunderbolt 3 Devices per Port
  + Supports Up to 8K Display

- USB
 + 5 x USB 2.0 (1 Rear, 4 Front)
 + 6 x USB 5Gbps Type-A (4 Rear, 2 Front)
 + 4 x USB 10Gbps Type-A (Rear)
 + 1 x USB 10Gbps Type-C (Rear)
 + 1 x USB 20Gbps Type-C (Front, USB PD 27W)

- LAN: Intel Killer E5000B 5G LAN

- Internal IO
 + 1 x Thunderbolt 5 Card Connector (JTBT5, RTD3)
 + 1 x ATX Power (ATX_PWR)
 + 2  CPU Power (CPU_PWR)
 + 1 x PCIe 8-pin Power (PCIE_PWR)
 + 1 x CPU Fan
 + 1 x Combo Fan (Pump/SYS Fan)
 + 6 x System Fans
 + 1 x EZ Conn Header (JAF_2)
 + 2 x Front Panel (JFP)
 + 1 x Chassis Intrusion (JCI)
 + 1 x Front Audio (JAUD)
 + 1 x Thermal Sensor (T_SEN)
 + 3 x ARGB Gen2 (JARGB_V2)
 + 1 x RGB LED (JRGB)
 + 1 x TPM Header (TPM 2.0)
 + 4 x USB 2.0
 + 2 x USB 5Gbps Type-A
 + 1 x USB 20Gbps Type-C

- WIRELESS LAN & BLUETOOTH
 +  Intel Killer BE1750x Wi-Fi 7
 + Pre-installed M.2 Key-E Module
 + Up to 5.8Gbps (2.4/5/6GHz, 320MHz)
 + 802.11 a/b/g/n/ac/ax/be
 + Bluetooth 5.4, MLO, 4K-QAM

- LED FEATURE: 4x EZ Debug LED, 1x EZ Digit Debug LED

- OPERATING SYSTEM: Support for Windows 11 64-bit

- PCB Info: ATX (243.84mmx304.8mm)
