Mainboard MSI MAG Z890 TOMAHAWK WIFI

📌 Cam Kết của KHO CÔNG NGHỆ ONLINE
✍️ Sản phẩm mới chính hãng 100%
✍️ Bảo hành 36 Tháng - Tại TTBH của Hãng hoặc Shop đều được ( qua serial trên sản phẩm)
✍️ Đổi trả 15 ngày đầu: Với các lỗi nhà sản xuất, hư hỏng trong quá trình vận chuyển, giao sai hoặc thiếu phụ kiện.
_________________________

Thông số kỹ thuật:

- Chipset: INTEL Z890

- CPU: LGA 1851, Supports Intel Core Ultra Processors (Series 2)

- Memory
  + 4x DDR5 UDIMM, Maximum Memory Capacity 256GB
  + Memory Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s
  + Max. overclocking frequency:
  • 1DPC 1R Max speed up to 9200+ MT/s
  • 1DPC 2R Max speed up to 7200+ MT/s
  • 2DPC 1R Max speed up to 6400+ MT/s
  • 2DPC 2R Max speed up to 5600+ MT/s
  + Supports Intel POR Speed and JEDEC Speed
  + Supports Memory Overclocking and Intel XMP 3.0
  + Supports Dual-Controller Dual-Channel mode
  + Supports Non-ECC, Un-buffered memory
  + Supports CUDIMM

- Onboard Graphics
 + 1 x HDMI 2.1 (Up to 4K 120Hz)
 + 2 x Thunderbolt 4 (USB Type-C, DisplayPort 2.1, Up to 4K 120Hz / 8K 60Hz)

- Slot
  + 3 x PCIe x16 Slots
  + PCI_E1: PCIe 5.0 x16 (CPU)
  + PCI_E2: PCIe 4.0 x4 (Chipset)
  + PCI_E3: PCIe 4.0 x4 (Chipset)

- Audio
  + Realtek ALC1220P Codec
  + 7.1-Channel High Definition Audio
  + Supports S/PDIF output

- Storage
  + 4x M.2
  + M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
  + M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices
  + M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
  + M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
  + 4x SATA 6G

- RAID:
  + Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices / for M.2 NVMe storage devices

- Onboard Thunderbolt
  + 2 × Thunderbolt 4 Ports (Rear)
  + Up to 40Gbps (Thunderbolt), 20Gbps (USB4), 10Gbps (USB 3.2)
  + 5V/3A (15W) Power Charging
  + Daisy-chain: Up to 3 Thunderbolt 4 or 5 Thunderbolt 3 Devices per Port
  + Supports Up to 8K Display

- USB
 + 4 × USB 2.0 (Front)
 + 6 x USB 5Gbps Type-A (4 Rear, 2 Front)
 + 3 x USB 10Gbps Type-A (Rear)
 + 1 x USB 10Gbps Type-C (Rear)
 + 1 x USB 20Gbps Type-C (Front)

*USB 20Gbps Type-C (Front) support USB PD 27W fast charging for JUSBC1

- LAN: Intel Killer E5000 5Gbps LAN

- Internal IO

 + 1 x Thunderbolt 5 Card Connector (JTBT5, RTD3)
 + 1 x ATX Power (ATX_PWR)
 + 2 x CPU Power (CPU_PWR)
 + 1 x PCIe 8-pin Power (PCIE_PWR)
 + 1 x CPU Fan
 + 1 x Combo Fan (Pump/SYS Fan)
 + 6 x System Fan
 + 1 x EZ Conn Header (JAF_2)
 + 2 x Front Panel (JFP)
 + 1 x Chassis Intrusion (JCI)
 + 1 x Front Audio (JAUD)
 + 3 x ARGB Gen2 (JARGB_V2)
 + 1 x RGB LED (JRGB)
 + 1 x TPM Header (TPM 2.0)
 + 4 x USB 2.0
 + 2 x USB 5Gbps Type-A
 + 1 x USB 20Gbps Type-C

- WIRELESS LAN & BLUETOOTH
 +  Intel Killer BE1750x Wi-Fi 7
 + Pre-installed M.2 Key-E Module
 + Up to 5.8Gbps (2.4/5/6GHz, 320MHz)
 + 802.11 a/b/g/n/ac/ax/be
 + Bluetooth® 5.4, MLO, 4K-QAM

- LED FEATURE: 4x EZ Debug LED, 1x EZ Digit Debug LED

- OPERATING SYSTEM: Support for Windows 11 64-bit

- PCB Info: ATX (243.84mmx304.8mm)
